Description
Digital Program box for SeaKing Marine Esc’s, EZ Run Car Esc’s and Hobbywing v2 car esc’s.
Programs Seaking v1, v2, v3 and Leopard Branded Seaking 60, 90, 120, 130HV and 180 amp esc’s from v1 to v3.
Allows for quick and easy programming without needing to use the transmitter.
Program the following Seaking Boat ESC parameters:
1)Forward/Forward & Reverse.
2)Number of cells(Auto or Select your own Cell Count)
3)Low Voltage Cutoff, Program Cutoff Voltage (No Cutoff, 2.8, 3.0v, 3.2v, 3.4v)
4)Timing (0.0, 3.75, 7.5, 11.25, 15.0, 18.25, 22.0, 26.25
Special Instructions for Programming SeaKing 130HV, Requires 4.8 to 6v receiver pack to power program card
1. There are 2 control wires on the ESC, the long one is used to connect to the receiver, and the short one is used to connect with the program box.
2. You must supply the program box with an additional battery because the Seaking-130A-HV ESC has no built-in BEC.
3. Please follow the sequences below:
a. Connect the program box with the ESC through the programming wire (shorter wire).
b. Connect the battery pack (4.8V to 6V) to the Program box. The box will light up with ” – – – “
c. Connect the main battery pack to the ESC. A few seconds after you plug in the main batteries the ” – – – “lighting will switch to “1 1”
IMPORTANT! Steps a to c cannot be reversed.
4. Program as needed
Includes:
(1) Program Card
(1) adapter wire for programming a Version 3 Seaking or Leopard V3 esc.
As of 1/1/2016, this card has the three program tables printed onto the card.
Table 1 EZrun Max
Table 2 Car ESC v2
Table 3 Seaking Boat ESC
NOTE: Will not program Seaking Pro 160 or Seaking v4 esc’s
