Hitec Standard Digital High Torque Waterproof Metal Gear Servo

Description

Standard Digital High Torque Waterproof Metal Gear Servo

Application: 12-15lb sport, 3D performance & scale, planes, 2M up sailplanes, 600mm electric heli, 50-59 class gas helis, 1M & scale sailboats, 1:10 scale on/off-road vehicles & power boats

Bearing: Dual

Bushing Or Bearing: Bearing

Current Draw Idle: 4.5mA

Current Draw Stall: 2,100mA

 Gear Type: Metal

Maximum Servo Speed: 0.150-0.199 sec

Maximum Servo Torque:100-199 oz-in

Motor Type: 3-pole metal brush ferrite

Product Height: 1.57″ (40.0mm)

Product Length: 1.65 in (41.8mm)

Product Weight: 1.00 oz (28.5g)

Product Width: 0.83 in (21.0mm)

Programmable: Yes

Servo Operating Voltage: 6.0 – 7.4V (HV)

Servo Size Category: Standard Servo

Type: Digital

Spline Count: 24 Teeth

Water-Resistant: Yes
