Description
High-mount fiberglass, Water cooled heavy duty motor mount for 40mm motors
This is for mounting a motor on a flat surface, for example, riggers, cats, and hydros. The higher fiberglass stands allow more clearance for the water jacket.
Fits 40mm diameter motors that are 60mm or longer in length, for example, TP 40xx, Leopard 4074, 4082, and 4092 brushless Motors.
Both water cooled and adjustable. The rear motor clamp helps carry the weight of the heavier/longer 40mm motors. The angle is adjustable to allow straight alignment with flex cable.
The anodized aluminum mounting plate with extended fiberglass mounting stands to distribute the weight of the motor over a larger area for added strength. The mounting plates have holes drilled in the bottom to allow epoxy to flow into them to make a superior bond to the hull.
Applications:
Fits most 40mm motors that are 60mm or longer.
For example Tp40xx, Leopard 4065, 4074, 4082 and 4092
Will fit up to a 50mm long water jacket.
Measures:
Total width of 58mm including the mounting stands.
Metal center mounts measure 53mm wide.
Requires you to provide motor mounting screws.
Comes with a mount only.
Note: This mount can also fit a vee bottom hull, but we suggest the lower ose-80600 or ose-80610 for a lower center of gravity in hulls with a vee.
